MF-GENERATOR 3.0 – 22kW, 400V is a compact, powerful middle frequency generator with a 7-inch display, dual temperature sensing, data logging, and adaptable inductor options for diverse industrial heating needs.
Available on backorder
Middle Frequency Generators: The 22kW V3.0, 400V Breakthrough: In the world of industrial heating, the right equipment can be the difference between a successful process and a disaster. The need for precision, efficiency, and reliability has always driven innovation. One such groundbreaking development is the MF-GENERATOR 3.0 – 22kW, a 400V Middle Frequency Generator, designed to meet the most demanding requirements of modern heating applications.
Compact, Advanced Design
The very first thing you’ll notice about this state-of-the-art machine is its compact design, measuring just 600x300x600 mm in dimensions. Don’t let the size deceive you; this is a powerhouse. With a weight of 46 kg, it’s designed to be both durable and portable.
The generator also boasts a large 7-inch display, providing users with a clear and comprehensive visualization of the heating process. This feature is not merely aesthetic; it’s functional. The display shows the temperature development in a chart form, allowing operators to monitor and adjust the process in real-time.
Smart Heating
The MF-GENERATOR 3.0 comes equipped with a heating system that operates based on a preset temperature/time curve. This ensures uniform heating, which is crucial for many industrial applications. Moreover, the machine has an adjustable power control, allowing the user to fine-tune the power output for specific tasks.
Additionally, the generator is intelligent enough to provide advice to the user on optimal heating. Whether it’s more or fewer windings, the smart electronics ensure that the device operates at the most optimal frequency.
Dual Temperature Sensing and Logging
With dual temperature sensing, the MF-GENERATOR 3.0 can monitor differences in temperature (ΔT), ensuring that the heating process remains stable and consistent. Any significant deviations can be easily detected and corrected.
One of the standout features of this machine is its ability to log the heating cycle. Users have the option to store data internally or export it to a USB stick for further analysis or record-keeping. This feature can be invaluable in environments where quality control and documentation are paramount.
Inductors: Fixed or Flexible
The versatility of the MF-GENERATOR 3.0 is evident in its compatibility with both fixed and flexible inductors. Depending on the workpiece application, users can choose between:
- Fixed Inductors: Ideal for removing labyrinth rings and sleeves.
- Flexible Inductors: These can be wrapped around the workpiece or placed inside, giving users more flexibility and adaptability for various heating tasks.
Detailed Specifications
- Power: A formidable 22 kW
- Frequency Reach: Ranges between 10-25 kHz
- Voltage/Amp: Operates at 3~400V/32A
- Temperature Measurement: Compatible with type K thermocouples, it can measure up to a maximum temperature of 300 °C / 572 °F with an accuracy of ± 38.2°F / ± 3.5°C.
- Inbuilt Features: From inductor recognition to an extra thermo couple input, and touchscreen controls for various setpoints and readings, this machine is designed for precision and ease of use.
- Product Number: 33022400
- Cooling Method: Forced air cooling
- Power: 22 kW
- Frequency Range: 10-25 kHz
- Voltage/Ampere: 3~400V/32A
- Operating Frequency: 50/60 Hz
- Temperature Measurement: Compatible with type K thermocouples
- Max. Temperature: 300 °C / 572 °F
- Accuracy: ± 38.2°F / ± 3.5°C
- Inductor Recognition: Yes
- Temperature Sensor: Two pieces, for a max of 300°C / 572°F
- Extra Thermo Couple Input: Yes
- Dimensions: 600x300x600 mm (LxWxH)
- Weight: 46 kg
- Display: 7-inch
- Heating Curve Display: Yes
- Delta T: Displayed via touchscreen
- Setpoint Power: Via touchscreen
- Setpoint Temperature: Via touchscreen
- Setpoint Timer: Yes
- Digital Readings: Temperature, time, power, and frequency all available on touchscreen
- USB Connection: Yes
- Network Connection: Yes
- Heat Log: Yes
- Signaling: Operational state via touchscreen, acoustic signals for error messages and end of heating cycle. Signal tower is optional.
Connectivity and Alerts
Modern industrial equipment needs to be connected and communicative. This generator comes with both USB and network connections, allowing for easy data transfer and integration into larger systems.
Operational states are clearly signaled, ensuring operators are always aware of the machine’s status. Should there be any errors, acoustic signals will alert the user, minimizing any potential downtime or damage. Plus, an optional signal tower can be added for further alert functionalities.
Options of the BETEX flexible inductors:
| Product Number | Length (m¹) | Diameter (Ø mm) | Max. Temp | Power (kW) | Weight (kg) | Short Use |
|---|---|---|---|---|---|---|
| 350200815 | 15 | 12 | 180°C | 22 | 5 | Yes |
| 350200820 | 20 | 12 | 180°C | 22 | 7 | Yes |
| 350200825 | 25 | 12 | 180°C | 22 | 9 | Yes |
| 350200830 | 30 | 12 | 180°C | 22 | 11 | Yes |
| 350200915 | 15 | 15 | 180°C | 22 | 7 | – |
| 350200920 | 20 | 15 | 180°C | 22 | 9 | – |
| 350200925 | 25 | 15 | 180°C | 22 | 11 | – |
| 350200930 | 30 | 15 | 180°C | 22 | 14 | – |
| 350200935 | 35 | 15 | 180°C | 22 | 18 | – |
| 350200715 | 15 | 20 | 300°C | 22 | 9 | – |
| 350200720 | 20 | 20 | 300°C | 22 | 12 | – |
| 350200725 | 25 | 20 | 300°C | 22 | 16 | – |
| 350200730 | 30 | 20 | 300°C | 22 | 18 | – |
This table provides a clearer overview of the different BETEX flexible inductors, their
The MF-GENERATOR 3.0 – 22kW, 400V represents the pinnacle of middle frequency generators in today’s market. Combining power with precision, versatility with user-friendliness, it stands as a testament to what modern engineering and design can achieve. Whether you’re in the business of metalwork, manufacturing, or any industry requiring controlled heating, this generator is worth considering as a staple for your operations.
