Hydraulic flange spreader SW15TE MAXI-KIT, 31T Equalizer

Hydraulic flange spreader 31T Equalizer SW15TEMAXSPB MAXI-KIT. The SW15TEMAXI Hydraulic Flange Spreader Kit stands out as a versatile and efficient tool designed for a variety of applications. From construction to routine maintenance, this kit offers a combination of strength, precision, and ease of use. Let’s delve deeper into its components, features, and benefits.

Components of the Maxi Kit

• Flange Spreader Wedge Heads: The kit includes 2 SW15TE Flange Spreader Wedge heads, known for their reliability and efficiency.
• Hydraulic Components: With 2 hydraulic hoses and cylinders, both rated at a pressure of 10,000 psi (700 bar), and an HP350D sealed hand pump with gauges, the kit is ready for heavy-duty tasks.
• Safety and Stability: The inclusion of 2 safety blocks and 2 pairs of stepped blocks ensures that operations remain safe and stable.
• Additional Components: The kit is completed with an instruction manual for clarity on operations and a sturdy plastic carry case for easy transport and storage. The gross kit weight stands at 31 kg (68.3 lbs), making it manageable for transport.

Features & Benefits

Functional Versatility: The SW15TEMAXI is not just a tool but a comprehensive solution for:

• Commissioning
• Construction
• Routine Maintenance
• Shutdowns/Outages
• Testing
• Valve Change-outs

Unique Special Features:

• An interlocking first step ensures that the tool is firmly in place.
• A deep 15 mm secure hold on the first step, coupled with a required access gap of only 6 mm, ensures compatibility with a wide range of flanges.
• The tool is lightweight, yet robust, guaranteeing longevity and ease of use.
• A powerful spreading force of 30 T (155 kN) can be achieved from a hydraulic pressure of 10,000 psi (700 bar).
• The automatic mechanical retraction offers an additional layer of safety and convenience.

Operating Benefits:

• Secure hold on each step guarantees stable operations.
• Quick and easy to operate, resulting in saved time and reduced costs.
• Designed with safety in mind, ensuring that all operations are risk-free.
• Despite its robust features, the tool remains portable, making it perfect for on-site tasks.

Stepped Blocks: These are essential for ensuring the tool’s stability during operations. The kit includes 2 stepped blocks, screws, and a hex key, with a gross weight of 1.5 kg (3.5 lbs).

SW15TEMAXI Hydraulic Flange Spreader Kit is a perfect blend of strength, precision, and versatility. Its unique features, combined with its functional benefits, make it an indispensable tool for professionals. Whether you’re looking to perform routine maintenance or handle heavy-duty construction tasks, this tool is an excellent choice for ensuring efficient and safe operations.

Spreading force with 700 bar (10000 psi).
Hydraulic pressure applied: 15.5 T (155 kN) per tool
It is recommended that tools are used in pairs giving: 2 x 15.5 T = 31 T (310 kN)

2 x SW15TE Wedge heads
2 x 700 bar (10 000 psi) Hydraulic Hose, 2 m (78.7”)
2 x 700 bar (10 000 psi) Hydraulic Cylinder
1 x 700 bar (10 000 psi) HP350D Sealed Hand Pump with Gauge
2 x Safety Blocks
2 x Pair of Stepped Blocks
2 x Hex Keys
1 x Instruction Manual
1 x Carry Case
Tool weight: 7.0 kg (15.4 lb)
Carry-Case: 6.0 kg (13.2 lb)
Gross weight: 31.0 kg (68.3 lb)
Carry-Case Dimensions: 920x520x210 mm (36.2” x 20.5” x 8.3”)

Safety block dimensions:Width 78mm, lenght 145mm, thickness shank 13mm, thickness body 27mm.
Width step: 28mm, 38mm, 48mm, 58mm, max 78mm.

STEPPED BLOCKS

Stepped Blocks can be used singly or in pairs
Increase the maximum spreading distance of the SW15TE to 81mm.
Stepped block: 0.52 kg (1.1 lb)
Gross weight: 1.5 kg (3.3 lb)
