Electric die stock REMS Amigo 2 with quick-change die heads

REMS Amigo 2 Electric die stock, equipped with quick-change die heads, is a powerful and user-friendly electric tool designed for threading tasks. With its unique support bracket, it is ready to use anywhere, even without a vice, making it ideal for repair, renovation, and job site applications.

Electric die stock REMS Amigo 2

1. Threading Capacity: Capable of threading pipe threads ranging from ⅛” to 2″ (16 – 50 mm) and bolt threads from 6 to 30 mm (¼” – 1″).
2. System Advantage: Utilizes one type of small, compact quick-change die heads and dies for all REMS die stocks, ensuring efficient and straightforward stocking with no confusion.
3. Support Bracket: Features a solid support bracket designed to withstand torque in both directions, offering secure clamping through an angular clamping spindle with a self-supporting effect. Mounting the die stock onto the support bracket and pipe is simple and straightforward.
4. Design: Compact, robust, and job site-proven design allows for use anywhere, even without a vice. The slender design enables operation in confined areas. The drive unit weighs only 6.5 kg (without the die head) for easy maneuverability, and it ensures a perfect seating of quick-change die heads.
5. Drive: Equipped with a solid, maintenance-free gear and a robust 1700 W universal motor, providing a 30% power increase thanks to automatic carbon brush adjustment during direction changes. It offers fast threading with a speed range of 30 – 18 rpm and includes a safety tip switch for added security.
6. Quick-Change Die Heads: Incorporates proven technology, high-grade materials, and precise machining to ensure excellent start-cutting performance and easy threading. No stalling of dies occurs, and long, precise pipe guidance ensures perfect pipe centering. Chip holes widen towards the outside to facilitate good chip flow and clean threads.
7. Dies: Utilizes proven, indestructible REMS quality dies with precise cutting geometry for excellent start-cutting performance, easy threading, and clean threads. Made of high-quality special-grade steel, fully tempered and hardened for an extremely long die life.
8. Thread-Cutting Oil: Compatible with REMS Sanitol and REMS Spezial, specially developed for threading, providing high cooling and lubricating effects essential for clean threads and prolonged service life of dies, tools, and machines.
9. Nipple-Threading: Efficient nipple-threading is achieved with the REMS Nippelspanner ⅜” – 1″ (2″), offering comprehensive threading solutions for various applications.

REMS Amigo 2 Set is an electric die stock kit equipped with quick-change die heads, designed for threading pipes ranging from ⅛” to 2″ (16 – 50 mm) and bolts from 6 to 30 mm (¼” – 1″). It supports both right and left-hand threading.

Key features of the REMS Amigo 2 Set include:

• Drive unit with maintenance-free gear, powerful 1700 W universal motor adaptable to 230 V or 110 V, 50 – 60 Hz.
• Safety tip switch and automatic carbon brush adjustment for increased power.
• Support bracket for both directions.
• REMS eva quick-change die heads for pipe threads, tapered to meet ISO 7–1, EN 10226 (DIN 2999, BSPT) standards for right-hand threading, suitable for electric conduit threading according to EN 60423 M.

Description Art.-No.

• Set R ½ + ¾ + 1 + 1¼ + 1½ + 2 (Art.-No. 540020)
• Set M 20 + 25 + 32 + 40 + 50 (M × 1.5) (Art.-No. 540022)

The REMS Amigo 2 Set for NPT threads is also available, with other voltage options available upon request. Each set comes in a sturdy steel case for convenient storage and transportation.

– ISO 7–1, EN 10226 (DIN 2999, BSPT), EN 60423 M
– Powerful universal motor 1700 W
– Automatic carbon brush adjustment.
– Right and left-hand rotation
– Ready for use any-where, without vice.
– Ideal for repair, renovation, job site.
– Pipe threads: ⅛ – 2″, 16 – 50 mm
– Bolt threads: 6 – 30 mm, ¼ – 1″
– Dual purpose holder for threading and sawing
– Steel case with inlay

The standard REMS Amigo 2 Set includes the following components:

• Electric die stock with quick-change die heads
• Support bracket for both directions
• REMS eva quick-change die heads for pipe threads, tapered to meet ISO 7–1, EN 10226 (DIN 2999, BSPT) standards for right-hand threading, suitable for electric conduit threading according to EN 60423 M
• Drive unit with maintenance-free gear and powerful 1700 W universal motor adaptable to 230 V or 110 V, 50 – 60 Hz
• Safety tip switch and automatic carbon brush adjustment for increased power
• Sturdy steel case for storage and transportation
