Digital Dial Indicator 242150, measuring rang 12.5 mm, IP 65

Digital Dial Indicator 242150 is a precision measuring instrument designed for accurate and reliable dimensional inspection in various industrial and laboratory applications. Engineered to meet IP65 standards, it is resistant to water and coolant as per DIN 40050/IEC 60529, making it suitable for challenging workshop environments.

1. Construction and Materials:
   • The mechanical components are constructed from hardened stainless steel, ensuring durability and resistance to wear.
   • The housing is made from high-quality aluminum with a front plate of robust plastic for enhanced longevity.
2. Display and Measurement System:
   • The instrument features a clear LCD with a digit height of 11 mm, offering excellent readability.
   • Measurement can be switched between millimeters (mm) and inches, supporting diverse measurement systems.
   • Supports absolute (ABS) and incremental (INC) measurement modes, providing flexibility in various tasks.
3. Functions:
   • Zero-setting capability at any position for quick calibration.
   • Preset value entry and ± pre-select functionality enhance measurement precision and efficiency.
4. Measurement Range and Accuracy:
   • Measurement range: 12.5 mm (0.5 inches).
   • Resolution: 0.001 mm (0.00005 inches).
   • Maximum permissible error: 0.003 mm.
5. Design Dimensions:
   • Dimensions: A = 65 mm, B = 30 mm, C = 59.5 mm, L = 145 mm.
   • The spindle diameter is 8 mm (h6 tolerance), compatible with standard accessories.
6. Power and Connectivity:
   • Powered by a 3V CR2032 battery, which is included in the package.
   • Mini USB output for efficient data transfer and integration with external systems. Additional cables for data transfer can be acquired (Art. No. 2420192).
7. Additional Features:
   • Comes with an operation manual for easy setup and usage.
   • Spare rubber sleeve available as an option (Art. No. 249915).
8. Certification and Standards:
   • Fully compliant with European CE regulations.

Applications:
Ideal for tasks requiring precise linear measurements, such as quality control inspections in manufacturing and mechanical engineering. The robust design ensures longevity, even under demanding operational conditions.

Specifications for Digital Dial Indicator 242150

• Measurement Range: 12.5 mm (0.5 inches)
• Resolution: 0.001 mm (0.00005 inches)
• Accuracy: ±0.003 mm
• Maximum Permissible Error: 0.003 mm
• Display: LCD, digit height 11 mm
• Measurement Modes: ABS (absolute), INC (incremental)
• Switchable Units: mm/inch
• Power Supply: 3V CR2032 battery
• Output: Mini USB for data transfer
• Material: Hardened stainless steel (mechanical parts), aluminum housing, plastic front plate
• Protection Rating: IP65 (water and coolant proof)
• Dimensions:
  • A = 65 mm, B = 30 mm, C = 59.5 mm, L = 145 mm
• Spindle Diameter: 8 mm (h6 tolerance)
• Options: Spare rubber sleeve (Art. No. 249915), data cable (Art. No. 2420192)
• Compliance: CE certified, DIN 40050/IEC 60529 standards.

This model, with its high resolution and accuracy, makes it suitable for applications requiring fine detail, such as toolmaking and calibration processes.
